10 Ton Double Girder EOT Crane Assembly (German Make)

10 Ton Double Girder EOT Crane Assembly (German Make)

| Parameter | Specification | Equipment | Double Girder Electric Overhead Travelling (EOT) Crane Assembly |
| Safe Working Load (SWL) | 10 Ton
| Crane Type | Double Girder Top Running EOT Crane
| Hoisting Arrangement | Wire Rope Hoist with Drum Assembly
| Duty Classification | M5 / M6 (Customizable up to M7)
| Span | As per Customer Requirement
| Lift Height | As per Customer Requirement
| Power Supply | 415V ±10%, 3 Phase, 50 Hz AC
| Control Voltage | 110V / 48V (Optional)
| Ambient Temperature | 5°C to 50°C

Hoisting Assembly
Hoist Capacity: 10 Ton
Drum Type: Grooved Seamless Steel Drum
Wire Rope: High Tensile Steel Wire Rope
Rope Construction: 6×36 / 6×37 IWRC or FC
Fall Arrangement: 2/4 Fall
Brake Type: Electromagnetic Fail Safe Brake
Limit Switch: Upper & Lower Limit Switch
Overload Protection: Available (Optional)

German Make Drive Unit

The crane is equipped with a premium German Make SEW-Eurodrive Geared Motor, ensuring exceptional reliability and long service life.

Drive Features
SEW-Eurodrive Geared Motor
Heavy Duty Helical Gearbox
High Starting Torque
Low Noise Operation
High Mechanical Efficiency
Compact Design
Continuous Duty (S4/S5)
IP55 Protection
Class F Insulation
Long Service Life
Drum Assembly
Heavy Duty Fabricated Drum
Precision Machined Rope Grooves
Dynamic Balanced Construction
High Strength Steel Material
Smooth Rope Winding
Long Service Life

Gearbox
Parameter | Details
Make | SEW-Eurodrive (Germany)
Type | Helical Geared Motor
Lubrication | Oil Lubricated
Housing | Heavy Duty Cast Iron
Efficiency | High Efficiency Transmission

Electric Motor
| Parameter | Details
| Make | SEW-Eurodrive
| Type | Squirrel Cage Induction Motor
| Protection | IP55
| Insulation | Class F
| Duty | S4/S5
| Frequency | 50 Hz
| Voltage | 415 Volt

Mechanical Features
Heavy Duty Fabricated Base Frame
Precision Machined Components
Anti-Vibration Mounting
High Load Bearing Capacity
Easy Maintenance Design
Corrosion Resistant Finish
Heavy Duty Bearing Arrangement
Robust Structural Construction

Safety Features
Electromagnetic Brake
Mechanical End Stops
Rope Guide
Upper & Lower Limit Switches
Emergency Stop Provision
Safety Guards
Anti-Drop Design
Overload Protection (Optional)

Standard Painting
Surface cleaned by shot blasting / mechanical cleaning
One coat Zinc/Red Oxide Epoxy Primer
Two coats Industrial Synthetic Polyurethane Finish Paint
Standard Safety Yellow (RAL 1003) Finish
Total Dry Film Thickness: 120–160 Microns

Standard Supply Includes
Hoisting Drum Assembly
SEW German Make Geared Motor
Heavy Duty Gearbox
Base Frame
Wire Rope Drum
Couplings
Bearings
Safety Guards
Fasteners
Electrical Junction Box

Applications
Steel Plants
Rolling Mills
Heavy Engineering Industries
Fabrication Workshops
Automobile Industries
Power Plants
Cement Plants
Shipyards
Foundries
Warehouses

Key Advantages
German Make SEW-Eurodrive Drive System
Heavy Duty Industrial Design
High Efficiency & Low Power Consumption
Smooth and Precise Lifting
Low Noise & Vibration
Long Service Life
Easy Maintenance
Reliable Performance in Continuous Operation
Designed for Heavy Industrial Applications
Manufactured with Premium Quality Components by NEER INDUSTRIES
